vuicci controller-A-01
VUICCI 30A Boost MPPT Solar Charge Controller 1200W for 48V60V72V Batteries | 12-60V to 48V/60V/72V Step-Up | Solar Panel Regulator for LiFePO4/Lead-Acid/AGM/Gel | RV Golf Cart Off-Grid| 1-Year Warranty
In Stock
Boost MPPT controller that steps 12–60 V panel input up to charge 48V, 60V or 72V batteries, a design no other controller listed offers. It supports LiFePO4, NMC, lead-acid, AGM and gel, with up to 1200 W of panels, a color LCD, metal housing and fan cooling, fitting golf carts and high-voltage banks rather than typical 12V van systems. The title gives 30 A, while the features describe 30 A of PV input and 15 A of battery charging current.
- Price
- $45.99
- Brand
- vuicci
Prices from Amazon as of . Product prices and availability are accurate as of the date and time indicated and are subject to change. Any price and availability information displayed on Amazon at the time of purchase will apply to the purchase of the product. As an Amazon Associate I earn from qualifying purchases.
How it compares
Compared with the other solar charge controllers on this site that list each value:
- Width 2.36 in.: the lowest of 23
- Width 60 mm: the lowest of 22
Specifications
These details are subject to change and may not be current. Please check Amazon or manufacturer web site to confirm before purchase.
- Model
- controller-A-01
Physical Attributes
- Weight
- 1.80 lbs
- Weight
- 0.82 kg
- Length
- 6.70 in.
- Length
- 170 mm
- Width
- 2.36 in.
- Width
- 60 mm
- Depth/Height
- 3.70 in.
- Depth/Height
- 94 mm
More specifications
- Warranty
- 1 Year
Physical Attributes
- Housing material
- Metal
Safety
- Overheat protection
- Yes
- Low-voltage protection
- Yes
Physical Attributes
- Display type
- Color LCD
Core specs
- Controller type
- MPPT
- Battery system voltages
- 48/60/72V
Charging
- Peak conversion efficiency
- 98.0 %
- MPPT tracking efficiency
- 99.0 %
- Battery types supported
- LiFePO4, NMC, Lead-Acid, AGM, Gel
Physical Attributes
- Cooling
- Fan
Safety
- Reverse polarity protection
- Yes
Features
- 【High-Efficiency MPPT Solar Panel Controller | Boost Voltage Design】This 30A MPPT solar charge controller features a built-in boost module, stepping 12V-60V solar panel input up to steady 48V/60V/72V output. Boasting 99% tracking rate and 98% conversion efficiency, it fully solves low voltage problems, and maximizes power generation for 10W to 1200W solar panels. It works stably even on cloudy days or in dim light
- 【5-in-1 Battery Compatibility】Compatible with LiFePO4, NMC (Ternary Lithium), Lead-Acid, AGM, and Gel batteries. Supports 48V/60V/72V battery systems with up to 30A PV input current and 15A battery charging current—ideal for golf carts, RVs, yachts, and off-grid solar systems
- 【Full Metal Housing & Excellent Heat Dissipation】Adopting solid all-metal casing instead of fragile ABS plastic, the controller delivers outstanding durability and long service life. The optimized air duct structure accelerates heat dissipation perfectly, keeping stable performance during long-time high-power operation, perfectly suited for harsh outdoor environments
- 【Intelligent Heat Dissipation & All-Round Safety Protection】Equipped with built-in intelligent temperature-controlled cooling fan, it automatically adjusts speed according to working temperature, achieving efficient heat dissipation and ultra-quiet operation, prolonging the service life of the controller. It has full multiple safety protections: over-voltage, over-current, overload, overheating, reverse polarity, short-circuit and low-voltage protection, fully guarding your battery
- 【Easy Install & Complete Package】MC4 Plug-and-Play design. Compact (6.7"×2.36"×3.7", 1.8 lbs). HD Color LCD shows real-time voltage, current & power. Includes: 1× Controller, 1× English Manual, 2× Spare Fuses. Backed by 12-Month Warranty & dedicated after-sales support
Similar products from other brands
Chosen for their similar specifications and price.
 This productvuicci controller-A-01 |
 Victron Energy SCC115045212 |
 OOYCYOO MPPT 100A |
 SOGTICPS SY10048 |
|
|---|---|---|---|---|
| Price | $45.99 | – | $27.99 | $37.99 |
| Model | controller-A-01 | SCC115045212 | MPPT 100A | SY10048 |
| USB-A ports count | – | – | 2 | 2 |
| Weight (lbs) | 1.80 | 2.76 | 0.62 | 1.85 |
| Weight (kg) | 0.82 | 1.25 | 0.28 | 0.84 |
| Length (in.) | 6.70 | 7.32 | 6.69 | 7.67 |
| Length (mm) | 170 | 186 | 170 | 195 |
| Width (in.) | 2.36 | 2.76 | 3.74 | 2.59 |
| Width (mm) | 60 | 70 | 95 | 66 |
| Depth/Height (in.) | 3.70 | 5.12 | 1.57 | 7.24 |
| Depth/Height (mm) | 94 | 130 | 40 | 184 |
| Warranty | 1 Year | – | 360 days | 1 Year |
| Certifications summary | – | EN/IEC 62109-1, UL 1741, CSA C22.2 | – | – |
| IP rating | – | IP43 | – | – |
| Operating temp min (℉) | – | -22 | 14 | – |
| Operating temp max (℉) | – | 140 | 140 | – |
| Operating temp min (℃) | – | -30 | -10 | – |
| Operating temp max (℃) | – | 60 | 60 | – |
| App connectivity | – | Bluetooth | – | – |
| Housing material | Metal | – | – | – |
| Overheat protection | Yes | Yes | – | Yes |
| Low-voltage protection | Yes | – | Yes | Yes |
| Display type | Color LCD | – | – | – |
| Controller type | MPPT | MPPT | – | – |
| Rated charge current (A) | – | 45 | 100 | 100 |
| Battery system voltages | 48/60/72V | 12/24/36/48V | – | – |
| Auto voltage detection | – | Yes | – | Yes |
| Max PV input voltage (Voc) (V) | – | 150 | – | 100 |
| Max solar input (12V battery) (W) | – | 650 | – | – |
| Max solar input (24V battery) (W) | – | 1,300 | – | – |
| Max solar input (48V battery) (W) | – | 2,600 | – | – |
| Peak conversion efficiency (%) | 98.0 | 98.0 | – | – |
| MPPT tracking efficiency (%) | 99.0 | – | 99.0 | – |
| Self-consumption (mA) | – | 20.0 | 13.0 | – |
| Battery types supported | LiFePO4, NMC, Lead-Acid, AGM, Gel | – | – | – |
| User-defined charge voltages | – | Yes | – | – |
| Built-in Bluetooth | – | Yes | – | – |
| Communication port | – | VE.Direct | – | – |
| Cooling | Fan | – | – | – |
| Max terminal wire size (AWG) | – | 6 | – | – |
| Max terminal wire size (mm²) (mm²) | – | 16 | – | – |
| Reverse polarity protection | Yes | Yes | Yes | Yes |
| UL 1741 listed | – | Yes | – | – |
| CSA C22.2 No. 107.1 | – | Yes | – | – |
| IEC 62109-1 certified | – | Yes | – | – |
